Wallpaper Rotogravure Printing Machine sugar film machine overseas services Stable and reliable
rotogravure printing production line.pdf
| Color quantity | 10 |
| Max. Width of printing | 1000mm |
| Mechanical speed | 180m/min |
| Printing speed | 150m/min (Variable because of different ink, film, familiarity of operator) |
| Length of printing cylinder | 480~1000mm |
| Dia. of printing cylinder | Φ120mm~Φ320mm |
| Color control precision | ±0.12mm (Variable because of different ink, film, familiarity of operator) |
| Max. unwind/rewind Dia.: | Φ600mm |
| Tension range | 3~50kgf |
| Tension control precision | ±0.5kgf |
| Core, I.D. of raw material | Φ76mm |
| Pneumatic source | 0.6Mpa |
| Impression roller pressure | 370kgf |
| Doctor blade transverse move range | ±5mm |
| Drying mode | Electrical heating |
| Heating power | 18×10=180Kw |
| Mail motor | 15Kw |
| Power consumption | 231kW |
| Machine size | 16500×3550×2850(mm) |
| Machine weight | 26000kg |
| Automatic speed up/down to the target speed gradually |
| Max. speed limit can be set for different material or cylinder size |
| Idle or running status can be exchanged |
Structure
- Driving by main motor through main shaft;
- Gear box for every printing unit with flexible connection by clutch;
- Independent groundwork for main motor and gear down device
Parameter
- Motor power 15kW
- Shaft Φ40mm
- Clutch flexible style
Feature
- Start at low speed with full load;
- Automatic speed acceleration;
- Integrated with the whole machine;
- Four stage tension control
- Safety light
- Main pneumatic source with oil/water filter
video link of LC-E model rotogravure printing machine (Aluminum foil, paper, plastic film)
https://youtu.be/NPGk7K2FOhQ
video link about LC-E model rotogravure printing machine (Export to Pakistan, print aluminum foil, BOPP, PE, PVC, PET,Paper)
https://youtu.be/lZ8PziP51Xk
After the machine delivery to customer’s factory, we will sent engineers or technician to client’s factory, within the appointed time to install the machines and train the operator for buyers. Engineer’s salary and transportation fee from our factory to the domestic airport or station is on our account.
During the installation, customers should offer Accommodation,Round-trip tickets, Visa cost for our engineers. working time is 8 hours per day. Salary is 80-150USD per day( it depends)
